The MDB TF Series is designed as a forestry mulcher, to cut brush, reeds, bamboo and hardwood trees for the Green Climber line.
We have distributors in every corner of the earth and they will be at your disposal for any machine service. Technicians are available from the diagnostic stage, the spare parts ordering stage through to installation.
The TF Series combines strong hydraulic pumps and rotating teeth which provides cutting power for grass, weeds, reeds, bamboo and small hardwood trees of up to 20 cm / 8 in.
The front breaker bar provides leverage in helping push materials over and the the front teeth provide control of cut materials from falling to the sides.
The optimized power transmission system features 4 belts to offer maximum reliability.
Strong and durable teeth reinforced with high resistance steel, combined with a fixed set of counter-rotating teeth result in a fine mulch.
Available in 3 different cutting widths: 125 cm, 130 cm and 150 cm: TF 125, TF 130 and TF 150.
Height-adjustable side skids for working a variety of terrains. It allows for a number of different cutting depths, adapting to different tasks at hand.
The tilting head allows for the flail to follow the uneven ground surface.
The front has a latch that can be opened via the remote control. Opening the latch allows for shredding vertical branches and small trees and shrubds, and closing the latch allows for finely mulching the debris on the ground.
The rear facing safety chains block flying objects and material from exiting the machine for optimal operator safety.
Features
| Teeth | Yes, 30 / 33 / 36 |
| Security | Rear chains |
| Floating plate | Yes |
| Access panel | Yes (hydraulically) |
| Ramming bar | Yes |
| Belt tensioner with check spring | Yes (patented) |
Hydraulics
| Transmission | Hydrostatic Proportional with 4 belts |
Dimensions
| Length | 760 mm / 870 mm / 870 mm |
| Width | 1450 mm / 1510 mm / 1660 mm |
| Height | 870 mm / 1000 mm / 1000 mm |
| Weight | 390 kg / 550 kg / 605 kg |
